Automatic Swing Gate

Automatic Swing Gate
Product name:Automatic Swing Gate
Item:K207A, K207U
Advanced Features
  • Self-locking and reversible electromechanical gearmotor
  • Body in die-case aluminum and high quality painted
  • Adjustable support brackets
  • Built-in micro switches for gate opening arrest
  • Opening angle up to 105 degree
  • One model only for left and right hand
  • Overheat or over-current protection
  • Time-delay protection
  • DC12V electric lock
  • Emergency release key in case of power failure
  • Control panel are available to photocell, alarm lamp & security device
  • Quick installation, full fitting accessories are provided in motor kits
Technical data
Model          K207A              K207U
 Motor Power   AC 110W  AC 100W
Power Supply  220~240V 110~120V
Opening Time  22sec
 Max. Thrust  1500N
 Working Angle   90° to 105°
 Remote Control    Rolling code 433.92mHz
 Max. Length Per Leaf   2.5m
Max. Weight Per Leaf  200KG
